Slotted spring pins are typically one piece, with a slot on one side that stays stationary once it is installed. Coiled spring pins have an internal coil that remains more dynamic after installation, which helps the fasteners absorb shock from the assembly and provides more flexibility than a slotted style. The crank mechanism socket and the side-mounted gear that meshes with b1 is on Fragment A. The back of the fragment contains the rearmost e and k gears for synthesis of the moon anomaly, noticeable also is the pin and slot mechanism of the k train. The Antikythera Mechanism Episode 9 - Making The Epicyclic Pin and Slot Gearing, by Clickspring.In this video I make what is arguably the most impressive sec.
You may think a Pin-in-a-Slot is a special type of joint. Note: A Pin-in-a-Slot is term a joint in which a Pin-Joint appears to move along a Slide-Joint. | ||||||
The mechanical-design of a Pin-in-a-Slot might be actually be similar to Diagram A, in which we see two Parts :
However, the kinematic-design of a Pin-in-a-Slot is always threeParts. Diagram Bshows a different mechanical configuration, with three Parts:
It helps me to imagine that Part is a Slide-Rail, and Part is a Sliding-Block that slides along the Slide-Rail. Diagram C shows a system that is a similar construction to Diagram B. Diagram C shows the Pin-Joint is that is offset to one side of the Slide-Joint. There are two examples of the Pin-in-a-Slot mechanisms, below. | ||||||
Cam-Follower in a Slot - Geneva Mechanism 'Expand' then 'Play' How to...Add a new Mechanism-Editor. | ||||||
'THK' Slider and Rail - Dwell Mechanism Pin-in-Slot Dyad and Mechanism How to...Add a new Mechanism-Editor. |
